Při zakoupení řadiče adaptec serie 6 z mé níže uvedené nabídky, obdržíte dárek v podobě ventilátoru od společnosti Noctua NF-A4x10 FLX. Všechny řadiče Adaptec RAID serie 6 mají na chladiči přípravu...
víceAdaptec 6805H Host Bus Adapter (HBAs) Single 2277900-R
Adaptec 6805H Host Bus Adapter (HBAs) Single 2277900-R
Zboží krátce použité a otestované 100% funkční
Bez krabice a příslušenství. (Spare part)
| Výrobce: | Adaptec |
| Kód: | ASA-6805h spare |
| Dostupnost: | Prodáno |
| Počet ks: | 0 ks |
6 790,- Kč3 490,- Kč
Adaptec 6805H Host Bus Adapter (HBAs) Single 2277900-R
Microsemi Adaptec ASA-6805H - storage controller - SATA 6Gb/s / SAS 6Gb/s - PCIe 2.0 x4
ADAPTEC HBA 6805H patří mezi kvalitní SAS/SATA řadiče pevných disků. Tento 8portový řadič je určen pro rozhraní PCI-Express x4.
Tento řadič nabízí kompletní podporu SAS (Serial Attached SCSI) a dále standard Serial ATA. PMC PM8001 SAS řadič podporuje SAS a SATA pevné disky HDD, SSD disky a disky SAS. Nabízí kratší Low-profile MD2 formát a podporuje SAS expandér.
Podporovány jsou operační systémy Windows, Red Hat Linux a VMware ESX.
The PMC Adaptec 6805H 6Gb/s PCIe Gen2 HBA offers the ideal economical solution for key servers requiring fundamental I/O connectivity on value server platforms
Operating System
| Microsoft Windows Debian Linux FreeBSD Red Hat Linux SUSE Linux Ubuntu Linux VMware ESX For a detailed list see ASK Answer ID 17283. |
|
| Benefits | |
| Cost effective I/O solution supporting SAS and SATA HDDs, SSDs, removable media, SAS tape drives. |
|
| Customer Needs | |
| Flexibility to install SAS and SATA drives; I/O connectivity offering broad compatibility, support for SAS expanders, and enclosure management. | |
| Key Features | |
| • Eight 6Gb/s ports • PMC PM8001 SAS protocol controller supports SAS and SATA HDDs, SSDs, and SAS tape drives • PCIe Gen2 x4 host interface • Shorter than Low-profile MD2 form factor • Support for SAS expanders • Enclosure management support via LED header and SES2/SGPIO • Up to 280,000 IOPS at 4 KB block size • Up to 1600 MB/s sequential throughput (64KB blocks) |
|
| Management Utilities | |
Adaptec BIOS Configuration Utility (CTRL + A) • Legacy configuration utility • Flashable BIOS support Adaptec uEFI BIOS Configuration Utility • HII based configuration utility • Flashable BIOS support |
|
| Data Transfer Rate | |
| 6 Gb/s per port | |
| Bus System Interface | |
| 4-Lane PCIe Gen2 | |
| Form Factor | |
| Low-profile form factor (2.535"H x 6.095"L) smaller than MD2 allows installation in condensed system designs | |
| Connector Configuration | |
| 2 internal (SFF-8087) Mini SAS | |
| Package Contents | |
| • Adaptec 6805H adapter • Additional low profile vented bracket *Single does not include cables |
|
| Physical Size | |
| 2.535"H x 6.095"L (64mm x 155mm) | |
| Operating Temperature | |
| 0°C to 55°C (with 200 LFM airflow) Note: This Adaptec card contains a powerful processor which requires adequate airflow to operate reliably. Please install this card only into server or PC chassis with recommended airflow (200 LFM). * Ambient temperature measured 1" away from the processor | |
| Operating Voltage | |
| 0.09A@ 3.3V 0.7A@ 12.0V | |
| Regulatory Certification | |
| CE, FCC, C-tick, VCCI, CNS, KCC, UL, BSMI | |
| Mean Time Before Failure (MTBF) | |
| 2,000,000 hours at 40°C | |
|
|
|
